Product Advantages

Factory membrane ageing, pre-delivery

Less membrane modules needed

Flexible mounting arrangements

Technical specifications

Performance data

Standard test criteria are at 7 barg, other specification points are an indication

Oxygen purity%	Minimum enriched oxygen flow rate in L/min
Oxygen purity%	28	30	32	34	36	38	40
4 barg	16.9	17.3	17.7	18.1	18.4	18.8	-
5 barg	21.5	22	22.5	23	23.5	24	24.5
6 barg	26.3	26.9	27.5	28.1	28.7	29.3	29.9
7 barg	31.1	31.9	32.6	33.3	34	34.7	35.4
8 barg	36.1	37	37.8	38.6	39.4	40.2	41.1
9 barg	41.3	42.2	43.1	44.1	45	45.9	46.9
10 barg	46.5	47.5	48.6	49.7	50.7	51.8	52.8
11 barg	51.9	53	54.2	55.4	56.6	57.8	58.9
12 barg	57.3	58.6	59.9	61.3	62.6	63.9	65.2

Oxygen purity%	Feed-air consumption at minimum enriched oxygen flow rate in L/min
Oxygen purity%	28	30	32	34	36	38	40
4 barg	24.5	28.4	33.4	41.3	77.1	77.1	-
5 barg	31.2	35.5	41.1	49.5	80.6	80.6	139
6 barg	38.1	43.3	50.2	58.1	92.2	92.2	138
7 barg	45.1	51.2	59.5	68.8	104	104	149
8 barg	52.4	59.4	69.0	79.9	120	120	166
9 barg	59.8	67.8	78.8	91.2	137	137	187
10 barg	67.4	76.6	88.8	103.0	158	158	219
11 barg	75.7	85.7	99.6	116.0	182	182	261
12 barg	83.7	95.0	110.0	129.0	208	208	310

Enriched oxygen flow exits at atmospheric pressure

Maximum pressure drop over nitrogen enriched flow <0.3 bar.

Maximum enriched oxygen flow rate = minimum flow rate + 30%

1.l/min refers to conditions at 1013 mbar(a) and 20°C

Ambient Conditions

Ambient temperatures		+2℃~+45℃
Ambient pressure		atmospheric
Air quality		clean air without contaminants

*Maximum inlet temperature, 35℃ when operating at 13 barg.

Materical applicable for EnOxy 304,604 606

Feed-air Conditions

Maximum operating pressure		13.0barg**
Min./Max. operating temperature		+2℃~+45℃
Maximum oil vapour contene		＜0.01mg/m³
Particles		filtered at 0.01 μm cut off
Relative humidity		＜100%（non condensing）

*Maximum inlet temperature, 35℃ when operating at 13 barg.
**Maximum inlet pressure, 10 barg when operating at 45℃.

Weight，Dimensions and Connections

Dimensions（HWD）		3868063mm
Weight		2.3kg
Connection feed-air		G3/8”female to ISO228
Connection nitrogen enriched air		G3/8”female toISO228
Connection enriched air at atmospheric pressure		G3/8”female toISO228
Dimensional drawing		Refer to K3.1.350

Flow Rate Corrections

Nitrogen flow rate at feed temperatures other than 20°C		Use bulletin S3.1.085*
Feed-air consumption at feed-air temperatures other than 20℃		Use bulletin S3.1.085*

*version number may vary, make sure to use the most recent version.
